Electrolyzer
Electrode area: 100cm² - 5000cm² 200-1000 A/m² Green hydrogen production, fuel cells
Sodium hypochlorite generator: MMO-coated titanium anode + titanium cathode Electrode thickness: 0.8mm - 3mm
Electrolyzer capacity: 1L - 100L 50-300 A/m² Swimming pool disinfection, drinking water sterilization, industrial water treatment
Metal plating electrolyzer: Platinum-plated titanium anode / lead dioxide anode + copper/nickel cathode Electrode thickness: 0.5mm - 5mm
Electrode area: 500cm² - 2m² 50-500 A/m² Gold, silver, copper, platinum, nickel and other metal plating
Wastewater treatment electrolyzer: MMO-coated titanium anode + stainless steel cathode Electrode thickness: 1mm - 5mm
Processing capacity: 1m³/h - 100m³/h 100-800 A/m² Industrial wastewater treatment, printing and dyeing wastewater treatment
Seawater electrolyzer: MMO coated titanium anode + titanium cathode Electrode thickness: 1mm - 3mm
Electrode area: 100cm² - 5000cm² 200-1000 A/m² Seawater desalination, chlor-alkali industry
Electrolytic synthesis electrolyzer: Lead dioxide anode + stainless steel cathode Electrode thickness: 1mm - 10mm
Electrode area: 0.5m² - 2m² 500-1000 A/m² Organic electrolysis, oxidation reaction, chemical synthesis Operating current range 10A - 10,000A
Operating voltage 2V - 100V
Operating temperature 5℃ - 80℃
pH Applicable range 0 - 14
Design life 2 - 20 years (depending on anode type)
- Product Description
Electrolyzer: Advanced Hydrogen Production Technology
Welcome to Baoji Xintailai Metal Co., Ltd., your trusted manufacturer and supplier of cutting-edge 【Electrolyzer】 systems. Our professional R&D team, skilled production personnel, and state-of-the-art equipment ensure the delivery of high-quality 【Electrolyzers】 tailored to your specific needs. With our expertise in titanium and other advanced materials, we offer superior products and comprehensive door-to-door service.
1. Product Introduction
Our 【Electrolyzer】 technology represents the forefront of hydrogen production, designed to meet the growing demand for clean energy solutions. These systems efficiently split water into hydrogen and oxygen using electricity, providing a sustainable method for producing high-purity hydrogen gas. Ideal for various industries, our 【Electrolyzers】 support decarbonization efforts and enable the transition to a greener future.
2. Product Specifications
| Specification | Details |
|---|---|
| Type | PEM (Proton Exchange Membrane) |
| Capacity | 1 MW - 10 MW (customizable) |
| Hydrogen Production Rate | Up to 200 Nm³/h per MW |
| Hydrogen Purity | 99.999% |
| Operating Pressure | Up to 30 bar |
| Stack Lifetime | >60,000 hours |
| Response Time | <1 second |
| Water Consumption | ~10 L/kg H₂ |
| Footprint | 40-100 m² per MW |
3. Product Features
- Modular design for easy scaling
- Rapid response to fluctuating power inputs
- Remote monitoring and control capabilities
- Integrated safety systems
- Compact footprint for space-efficient installation
- Low maintenance requirements
- Compatible with renewable energy sources
4. Product Advantages
- High efficiency: Up to 75% system efficiency
- Flexible operation: Handles variable loads from renewable sources
- Eco-friendly: Zero-emission hydrogen production
- Durable: Long-lasting components made from premium materials
- Cost-effective: Lower OPEX due to advanced design
- Scalable: Easily expandable to meet growing demand
5. Product Application Industries
Our Electrolyzers find applications across various sectors:
- Renewable Energy: Storing excess energy as hydrogen
- Industrial Gas: On-site hydrogen production for manufacturing
- Chemical/Petrochemical: Feedstock for various processes
- Steel Manufacturing: Green steel production using hydrogen
- Ammonia Production: Clean ammonia synthesis
- Transportation: Fuel for hydrogen vehicles and refueling stations
- Power Generation: Grid balancing and energy storage
- Electronics: Ultra-pure hydrogen for semiconductor fabrication
6. Product Manufacturing Process
- Design and Engineering: Customized system design
- Component Fabrication: Precision manufacturing of key parts
- Stack Assembly: Careful integration of membranes and electrodes
- System Integration: Combining stack with balance of plant
- Quality Control: Rigorous testing at each stage
- Final Assembly: Integration of all subsystems
- Performance Testing: Comprehensive system validation
- Packaging and Shipping: Secure preparation for delivery
7. OEM Service
We offer tailored OEM solutions to meet your specific requirements:
- Custom capacity and configuration options
- Integration support for existing systems
- Co-development opportunities for innovative applications
- White-labeling services available
- Ongoing technical support and training
8. FAQ
Q: What maintenance does an Electrolyzer require?
A: Regular maintenance includes water quality checks, filter replacements, and periodic stack inspections.
Q: Can your Electrolyzers work with renewable energy sources?
A: Yes, our systems are designed to operate efficiently with variable renewable inputs.
Q: What is the typical ROI for an Electrolyzer system?
A: ROI varies based on usage and energy costs but typically ranges from 3-7 years.
9. Contact Us
Ready to explore how our 【Electrolyzers】 can revolutionize your hydrogen production? Contact us today:
Tel & WhatsApp: +86-15319223116 / +8613335492266
Email: [email protected]
Address: Guojia Village Industrial Park, Maying Town, High-tech Development Zone, Baoji City, Shaanxi Province.
Discover the power of efficient, sustainable hydrogen production with Baoji Xintailai Metal Co., Ltd.'s advanced Electrolyzer technology. Let's build a cleaner future together!
